Features & Applications
Features
- Maximise productivity – lift the performance of your DSH 600-22 and DSH 700-22 battery cut-off saws to the next level by using diamond blades developed specially for these tools
- More cuts per charge – the thinner blade core consumes less power when slicing through the base material
- Smoother cuts – thanks to redesigned, lower-friction diamond segments
- Higher cutting performance, for longer – Hilti Equidist arranged diamond technology helps to make these some of our most durable and powerful diamond blades
- Strict quality standards – every diamond segment is laser welded and tested separately before any blade can leave the factory
Applications
- Cutting concrete and masonry – such as making new openings or cutting bricks, blocks and prefab elements to size
- Maximising overall tool performance when using DSH 600-22 and DSH 700-22 battery-powered cut-off saws
PRODUCT INFORMATION
Cutting disc 180/22mm SPX metal
- Item Number: 2205727
- # of items in Package: 1
Cutting disc 115/22mm SPX metal
- Item Number: 2314164
- # of items in Package: 1
Cutting disc 125/22mm SPX metal
- Item Number: 2314165
- # of items in Package: 1
Cutting disc 230/22mm SPX metal
- Item Number: 2314166
- # of items in Package: 1
Cutting disc 350/25mm SPX metal
- Item Number: 2314168
- # of items in Package: 1
TECHNICAL DATA
- Tool type : Battery cut-off saw
- Base material : Masonry, Natural stone, Concrete, Concrete (reinforced)
- Product class : Ultimate
- Wet or dry operation : Wet and dry
- Segment height : 10 mm
- Segment width : 2.8 mm
- Arbor size :25.4 mm
- Disc diameter :300 mm
- Blade/disc thickness : 1.8 mm
- Number of segments : 30
